Connect + switched to a + pad that only provides voltage when the remote control is turned on.ĭont be afraid to ask.

Connect + constant to a + pad where the batteries connect to your controller which should provide voltage even when the aircraft is turned off.

Connect ground to a ground pad on your rc board (or as close to the battery as possible).

Just find a place where the battery connects to the main board and tap in. The process is similar for the aircraft, but without the relay. After you pre-assemble the kit, all you need to do is connect the antenna connectors, and connect the power to your aircraft, using a multimeter to detect the correct location, or follow community supplied recommendations. If the written documentation is not simple enough, we have a wiring diagram that even a child could understand. If your equipment is not listed, the generic details will help you get started with any drone! Installation is easy The documentation includes community-sourced videos showing the installation process for different products. The details are available at our wiki site here. Our team have been working tirelessly on documentation for the booster board to make it even easier to install.

#DJI PHANTOM ANTENNA BOOSTER TEST MANUAL#

LED Indicators: RED LED = 2.4G mode, BLUE LED = 5.8G modeĬomprehensive manual and "community supplied" videos Just go fly! Our Booster kit maintains the aesthetics of the remote controller intact. Our Bi-Directional Booster kit works with the original antenna, and you don't need any bulky external reflectors. High gain antenna boosters sacrifice omnidirectional performance and concentrate all signals in one direction, which requires the UAV operator to point the antenna towards the UAV at all times. If you ignore where the aircraft is, you will lose the signal. The kit includes a relay for power isolation and a manual power switch if you prefer manual control.Īdvantages of power amplifier vs.Our kit includes a booster module for both Aircraft AND Remote-Control, which makes this kit superior to anything else on the market!.Supports all dual-frequency products of DJI and all dual-frequency drones.MAX RF Transmit Power = 2500 mW, Receive Gain = 13 dB.

#DJI PHANTOM ANTENNA BOOSTER TEST SOFTWARE#

These are bi-directional signal boosters, while RC only and software boost is uni-directional.Significantly enhances the signal while automatically identifying the frequency of the host signal and can switch frequency bands automatically.Our 2.4GHz & 5.8GHz dual-band 2.5W dual-band booster kit is compatible with anything that uses WiFi for transmission.Only order the FCC board if you live in the USA or Canada. I think you will solve all the problems following these directions.IMPORTANT: You must match the board to your country!

if the drone is flying just over your head, you must keep the antennas parallel to the ground with the Range Booster mounted backwards. the Range Booster should be mounted as soon as the signal looses part of its strenght and you note a lower level on the APP indicator unless you experience an evident signal decrease, the use of the Range Booster is not recommended in a short range, let's say with the drone distant not more than 1 - 1,5 kilometers using the Range Booster on the Phantom RC, you must be very careful to orient the antennas straight towards the drone the Range Booster has a parabolic shape that transforms the antennas from omnidirectional to unidirectional

the Antennas of the Phantom RC are omnidirectional, so the signal is normally spread 360 degrees around their axis It is very strange that you have not had a positive experience using a range booster with your Phantom.Īnyway, perhaps you need some practical advice to improve the performance of this accessory:
